Maximum Gauges
Steel: 24 GA.
- Grade C and D compatible
- Grade E is too hard and problematic
?
Aluminum: 0.032
Aluminum (optional): 0.040
Copper: 20 oz.
Power
- Electric Motor: 7 Amps
- Volts: 115 V
- Phase: Single
?
Roll forms a double lock seam in one pass
Can be converted to single lock with optional rolls
Weighs only 40 lbs.
Adjustable height 1" or 1-1/2"
For use with painted or unpainted material
Seams 30 ft. per minute
Spring loaded swing away handle
Note: prepare at least 16" with the 001 or 001C and 8" with the 099
Made in USA
